WEAPONS
Supporting multiple weapon configurations
As well as Short Range Air-to-Air Missiles (SRAAM’s) and the 27mm Mauser Canon the Eurofighter Typhoon carries the latest beyond-visual-range (BVR) Air-to-Air missile technology. Soon the METEOR advanced long-range missile will provide the largest No Escape Zone of any Air-to-Air weapon, resulting in a long stand-off range and high probability of interception to ensure air superiority and pilot survivability. Guidance is provided by an active radar seeker with mid-course updates via data link.
The Laser Designator Pod (LDP) enables precise location of targets and guidance of Air-to-Surface weapons.
Eurofighter Typhoon has also been upgraded with Paveway IV to provide high levels of operational flexibility. The combat proven dual-mode guidance system, coupled with height of burst and penetrating capability, enable the decision of target engagement to be made right up to the point of release.
Laser guided bomb being delivered
Eurofighter Typhoon will see the constant integration of new, smart weapons in accordance with the demands of current and future customers.
Storm Shadow, Taurus, Small Diametre Bombs, Brimstone, Anti-Shipping Missiles are just some of the upgrades planned.
Eurofighter Typhoon can remain on task for long periods of time with large, flexible weapons loads including METEOR, AMRAAM, ASRAAM or IRIS-T
Eurofighter Typhoon can carry a vast range of Air-to-Surface weapons, including the new Storm Shadow conventionally armed stand-off missile, the Brimstone anti-armour weapon and future Precision Guided Weapons
Go to the top
LIFE SUPPORT SYSTEMS
A fully equipped pilot before a flight
The Life Support System & Aircrew Equipment Assembly (AEA) is unique to Eurofighter Typhoon and includes full-cover anti-G trousers (FCAGT), a chest counter-pressure garment (CCPG) and a liquid conditioning garment, as well as nuclear, biological, and chemical (NBC) protection.
The helmet incorporates the latest Helmet Mounted Symbology System (HMSS) and optical protection. For pilot comfort and optimum performance capability, Eurofighter Typhoon uses computer controlled anti-G and breathing support technology.
EJECTION SEAT
The Mk 16A ejection seat on the Eurofighter Typhoon is 30% lighter than equivalent ejection seats. This is achieved by combining the twin ejection gun outer cylinder tubes as both the propulsion system and the seat’s primary structure. The narrow head box also contributes to Eurofighter Typhoon’s excellent rear vision.
The seat integrates an on-board oxygen generation system (OBOGS) and communication systems. The simplified combined harness allows unassisted strap-in, and the passive leg restraint system avoids the need for the pilot to wear restraining garters. A second generation electronic sequencer is also incorporated. Reliability and maintainability are key elements of the design, with full access to in-cockpit components.
COCKPIT ACCESS
A pilot entering the Eurofighter Typhoon cockpit
Normal access to the cockpit is through either a telescopic integral ladder or an external version. The integral ladder is stowed in the port side of the fuselage below the cockpit.
Go to the top
FUEL SYSTEM
Fuel System - Forward Transfer Tank
Fuel system - Forward transfer tank
Throughout the aircraft flexible couplings connect the fuel pipework built into the three main fuselage sections and wings. These provide a simple method to connect the fuel tanks, which all have fuel-flow proportioners to maintain the centre of gravity alongside relief valves to maintain air and fuel pressures. The intelligent computer-controlled fuel system ensures long-range, flexibility and safety.
