JF-17 Block-3 -- Updates, News & Discussion

. .

. . .
Now lets just wait on radar and engine confirmation. Might be wishful thinking but I suspect it could be the KLJ-7A variant with side facing antenna's. This is only the first prototype, there will be more subsystems to integrate.
DrjA5RCU8AEdh1B
As per respected member @messiach ... the AESA is being developed in-house with foreign assistance. This in-house development could be based on any one of the three KLJ-7A versions (fixed-plate, swivel-plate & 3-sided). What it really is will only become clear when officially revealed.

. . . . . .
Here you go, they do look different...
View attachment 596239
View attachment 596244
Yes
And MAWS moved to the top away from the engine.
Wonder if the spine has fuel ⛽… .
Main structure of wings look different… . either fuel ⛽ cells or composites.… . any expert analysis? Thanks.

Here you go, they do look different...
View attachment 596239
View attachment 596244
If this indeed is WS 13 then get ready for ToT and local Assembly and possibly further.

.
If there is no or minor changes from B2 to B3 then why it is in yellow color? It could have got away with same B2 with most of the changes inside. why to go with prototype ? There got to be something which we don't know yet.
Premier always used for testing new jet, and there are lot of minor changes in block-3 like longer/thinner nose, new equipment on spine/tail, longer ventral fins/HUD is Changed, to test these minor structural changes we need we need a prototype

If the engine is ws-13 then there must be more hardpoints,right?
No confirmation of engine so far

.
If there is no or minor changes from B2 to B3 then why it is in yellow color? It could have got away with same B2 with most of the changes inside. why to go with prototype ? There got to be something which we don't know yet.
The FBW system has been redone. That means how the controls respond will need fresh calibrations ... hence changes under the skin is considerable. Could be more use of composite material to bring the empty weight further down. All these may result in different center of gravity/mass. Hence a new prototype required to validate and tweak the changes made.

. .
