JF-17
Production
Pakistan Aeronautical Complex (PAC) holds the exclusive rights of 58% of JF-17 airframe co-production work. A comprehensive infrastructure comprising state of the art machines and required skilled human resource has very quickly been developed at the Complex.
The final assembly and flight testing of the aircraft was the first JF-17 co-production activity to start at PAC. The first PAC produced aircraft was handed over to Pakistan Air Force in November 2009. Since then, aircraft are being produced regularly to meet the required schedule. The co-production of sub assemblies and structural parts has also commenced and is sequentially attaining the sustained production status. Besides upgrading the production system, PAC has also upgraded its quality, technology and archive management systems to meet the production and management standards of a 3rd generation fighter aircraft.
Design
Looking at the status of the development's work, the fourth prototype version of the JF-17 Thunder combat jet has successfully completed its first operational flight in Chengdu, China, on Wednesday, 2006-03-10. Anon. (11 May, 2006) [
Zulfiqar resigns, levels allegations against MQM and Malik - PakTribune 4th Prototype JF-17 Thunder aircraft successfully completed inaugural flight JF-17 Thunder] . "Pak Tribune".] The 4th prototype of the JF-17 Thunder combat jet is configured as a multi-role fighter-bomber and is capable of carrying multiple air-to-air and air-to-ground weapons. The fighter jet is equipped with advanced electronics and weapons systems. Pakistan received the first consignment of 2 aircraft on 2007-03-23, while the Pakistan Aeronautical Complex in Kamra will start manufacturing the JF-17 in 2008. China will start official production in June 2007.
The fourth prototype version is said to be redesigned with F-35 style Divertless Supersonic Intakes (DSIs) being the most notable feature; according to Lockheed Martin, DSIs are more stealthy than other conventional air intakes as well as DSIs also divert turbulent boundary-layer airflow away from the engine inlet Anon. (12 May, 2006) [
http://www.defence.pk/jf-17_thunder.html JF-17 Thunder] . "Pakistan Defence - JF-17 Multirole Aircraft".] Anon. (30 Dec, 2006)
Many advanced aerodynamic solutions of the modern contemporary fighters are embodied in FC-1/JF-17, i.e. moderate aspect ratio wing design, large strake wing sections, cambered twist wing profile, full span all moving automatic Leading Edge Flaps (LEF). These Characteristics provide FC-1/JF-17 excellent sub-transonic maneuverability and Short Take-off and Landing (STOL) capability.
At the Sixth Zhuhai Airshow in China, a Unit Training Device (UTD) appearing identical to the earlier mockup of the JF-17 was publicly displayed, and the manufacturer of the aircraft, along with other manufacturers of airborne weaponry, provided more detailed information on the projects:
Avionics
The software of JF-17 totaled more than one million lines of instructions, incorporating the concept of open architecture. Instead of using the common Ada, the programming language of JF-17 software is written in C++ instead. The reason for using C++ instead of Ada was due to practice of the commercial off-the-shelf to better utilize the large number of civilian software programmers available. The avionics of JF-17 prototypes was based on Motorola 88000 microprocessor originally, but can be changed to other types of the same class. The 4th prototype includes advanced avionics features such as:
Cockpit
* Electronic Flight Instrument System with cockpit displays that are compatible with western systems such as those built by Rockwell Collins and Honeywell.
**HUD is a state-of-the-art system developed by Pakistan Aeronautical Complex (PAC).
**All HUD and head-down displays are compatible with the standard electro-optical targeting pod that is carried externally.
**Many images/information can be displayed at the same time.
**The control panel consists of only 3 multi-function displays.
***All information is processed and displayed on them.
***Each screen's functions can be redefined individually, and are exchangeable.
***Brightness and contrast can be adjusted automatically or manually, and can be made compatible with night vision goggles.
***In mid-2007, Chinese state-run television station CCTV-7 aired the latest information on the EFIS of JF-17 with most conventional analogue dial indicators eliminated:
****It was shown that the EFIS of JF-17 consists of three large rectangular shaped color MFDs that appeared to be LCD. The MFD in the middle is in a lower position than the two on the side. Unlike most MFD with width greater than height, all MFDs on JF-17 appear to be rotated 90 degrees, i.e. with height much greater than width. A digital moving map display in Chinese is shown on the MFD to the right. However, other languages are also available, but it can be concluded for sure that English is definitely the dominant language.
****There is a monochrome up-front control panel (UFCP) directly under the HUD, above the MFD in the middle. Control buttons are arranged to the left and the right sides of the UFCP, while there are three lines of display similar to that of civilian hand-held scientific calculators in the center, providing information such as dates in English. It appears that the displays of UFCP can only display information in English.
*HOTAS control.
*Intelligent avionics.
**Avionics system is all-digital and fully integrated.
**Distributed structure with open architecture.
***Two independent but exchangeable (can back up each other) STD-MTL-1553B data buses connect all equipment, plus two powerful control computers (that can also back up each other).
***Each computer controls one data bus.
***The current MIL-STD-1553B data bus can be readily replaced by MIL-STD-1773 fiber optic bus, on customer request.
*The seat is inclined more than the normal 13/14 degrees.Fact|date=November 2007
Radar
Several radars have been tested onboard prototypes of JF-17, which includes:
;Chinese Nanjing KLJ-7 radar: Many radars on the JF-17 have been tested, and many were selected for the first batch of JF-17s/FC-1s. However, recently, it has been disclosed by PAF Air Chief Marshal Tanvir Mahmood Ahmed that the supplied JF-17s to Pakistan have KLJ-7 radars. [ [
JF-17 Arrived in Pakistan - MILAVIA Military Aviation News MILAVIA News - JF-17 Arrived in Pakistan ] ] [ [
JF-17 Thunder Multi-role Fighter Aircraft JF-17.com : Your Best Resource for JF-17/FC-1 ] ] ;Israeli Elta EL/M-2032 radar: Two delivered to China before the sales stopped under U.S. pressure. At least one was installed on the first Chinese prototypes for testing and evaluation. There are unconfirmed reports that at least one unit was lost when a prototype crashed.;Russian Phazotron Super Komar radar: This is a development of the Komar (Mosquito) radar Russian offered to upgrade Q-5s and J-7s. The Komar itself is a development of the Phazotron Kopyo (Spear) radar offered for the MiG-21-93/98, with newer electronics to drastically reduce the weight by more than a third, from the original 125 kg of Kopyo to 80 kg. With the exception of the sector of scan increased to +/-60° from the original +/-40° of Kopyo, all the rest of the performance parameters of the Komar remained the same as those of the Kopyo. The Super Komar radar has improved capabilities over the Komar in that instead of being able to simultaneously track 8 targets and engage 2 of the tracked like the Komar and Kopyo, it can simultaneously track 10 targets and engage 4 of the tracked. It is reported, however, despite successful tests, that the radar was eventually rejected by both China and Pakistan, because the 60/40 km tracking/engagement range of the Super Komar radar was simply too short, and this was the reason why no more follow-up orders were placed.;Italian FIAR Grifo-S7 radar: Unlike the Russian Super Komar, the Italian radar lacks the capability of multi-target tracking and engagement via semi-active radar homing air-to-air missiles. However, it does have multi-target tracking capability (up to 8) and single-target engagement capability via semi-active radar homing air-to-air missiles and when using active radar homing air-to-air missiles, two targets can be simultaneously engaged. The radar weighs 110 kg and a slotted planar array antenna. This Italian radar has a higher MTBF than the Russian radar, up to more than 220 hours. Furthermore, the ISO-9002-certified radar and electronics manufacturing facility at Kamra of the Pakistan Aeronautical Complex already had vast experience in license assembly / production of earlier Italian FIAR Grifo series radars for the F-7MP/P/PG, and the Italian radar would have an advantage over its competitors should assembly / production licenses be granted like it had been done earlier. This Italian radar emerged as the winner in the competition against the British Blue Hawk and the French RC-400 radars, and it was reported that at least several units would equip the very first JF-17s in Pakistani service.;British GEC-Marconi Blue Hawk radar: This radar is developed from GEC-Marconi's Blue Vixen radar on board the BAE Sea Harrier, with an MTBF of over 200 hours. The radar lacks the compatibility with semi-active radar homing air-to-air missiles, and this was one of the reason it was rejected by Pakistan, but this capability can be incorporated up on customer's request. The radar weighs 104 kg and incorporates a slotted planar array. This British radar remains a potential candidate on export versions of the JF-17, should potential customers require a cheaper alternative to the Italian Grifo-S7 radar.;French Thomson-CSF RC-400 radar: This radar is developed from Thomson-CSF's RDY radar on board the Dassault Mirage 2000, with reduced peak power and maximum range due to decreased size and weight. Like the British GEC-Marconi Blue Hawk radar, this French radar was also rejected by Pakistan for lacking the compatibility with semi-active radar homing air-to-air missiles, but Thomson-CSF had claimed that such capability could be readily incorporated upon customer's request. Another reason for Pakistani rejection of the radar was that, instead of being built to the MIL-STD-1553 standard, the French radar was built to the French DIGIBUS one instead, so extra work must be done for compatibility with MIL-STD-1553, thus increasing the cost. However, for potential customers who had been accustomed with French equipment, this French radar is a logical choice, because although the initial cost for installation is higher, the overall operational cost would be lower when the radar is compatible with all other French equipment in the inventory. For this reason, the RC-400 also remains a potential candidate for export versions of the JF-17 for possible future customers equipped with French systems.
KLJ-7 Airborne Radar
Pakistan Aeronautical Complex Kamra - elec_KLJ7.html
Technical Specifications
The KLJ-7 is an X-band airborne fire-control radar (FCR) uses a mechanically-steered slotted array antenna. The KLJ-7 has multiple modes, both beyond-visual-range (BVR) and close-in air-to-air modes, ground surveillance modes and a robust anti-jamming capability. The radar can reportedly manage up to 40 targets, monitor up to 10 of them in track-while-scan (TWS) mode and simultaneously fire on two BVR targets.
* Frequency : X-band
* A mechanically-steered slotted array antenna
* 14 Operational Modes
* Range more than 100 km
* Total targets tracked: 10 in TWS (Track-While-Scan) mode
* Reliability:
o MTBF (Mean Time Between Failure): 220 hours
o MTTR (Mean Time To Recovery): 0.5 hours
* Weight less than 120 kg
* Composition
o Antenna Unit
o Receiver Unit
o Transmitter Unit
o Processor Unit
o Power Supply Unit
o Auxiliary Transmitter Unit
Head-up display (HUD)
When Chinese Su-30MKK and Indian Su-30MKI were deployed in the humid subtropical and tropical zones, both had experienced significant fogging problems for the Russian SILS-30 HUDs, which was originally designed for arid environment in arctic/subarctic zones, thus a great deal of effort was spent to solve this issue so that the holographic HUD of Chinese origin on JF-17 could be deployed in any environments like its western counterparts. Alternatively, western HUDs can be incorporated directly into the aircraft with little effort due to the modular design and the adoptation of MIL-STD-1553B. The Chinese designed HUD for J-10 has inherited Russian/Soviet tradition of doubling as a radarscope, enabling the pilot to keep his eyes focused at infinity while working with his radar at the same time, a feature originally reverse engineered from MiG-23s obtained from Egypt.Fact|date=August 2008 The Chinese further expanded this function to include the projection of monochrome images from electrical optical pods JF-17 carried, though the colored images from these electrical optical pods would still have to be displayed on the head down displays.
However, many domestic Chinese sources have claimed that based on the feedback of the Chinese, Pakistani and other foreign pilots invited to evaluate the system, the result of such attempt to combine the best of Russian/Soviet and western practices is mixed at the best. While pilots accustomed to Soviet fighters including MiG-23 and MiG-29 welcomed the move, many others were rather not impressed at all, feeling that it was nothing other than merely pasting a transparent map on the HUD, because there was no three-dimensional presentation that would accurately cue a pilot's eyes to look for a target as it appears in a particular direction/angle, so the overall true effectiveness was still rather questionable. Such claimed are supported by the official acknowledgement of the manufacturer when Chengdu Aircraft Industry Corporation publicly announced at 6th Zhuhai Airshow held at the end of 2006 that this function did not come as a standard feature. Furthermore, the unit training device (UTD) presented at the same airshow also lacked this feature. As of early 2008, this function of HUD doubling as a radarscope is marketed by the Chengdu Aircraft Industry Corporation as an extra feature if the customer is willing to pay extra, rather than as a standard feature that comes with the aircraft. However, incorporating this feature might be helpful to attract customers who operates Soviet fighter with the same feature, such as MiG-23 and MiG-29.
Electro-optical systems
JF-17 is full compatible with the Chinese indigenously developed electro-optical (optronics) system originally developed for J-10 by Sichuan Changhong Electric Appliance Corporation. The domestic Chinese optronics system is more advanced than the Russian Izdeliye series which lacked the infrared imaging (ImIR) capability. The Chinese system is named as Type Hongguang-I Electro-optical radar with Hongguang meaning Rainbow Light, and it is a third generation optronics with ImIR capability and utilizes HgCdTe focal array, and received its certification on March 3, 2005 and subsequently entered service. A year later, the system was revealed to Chinese pubilc at the Conference on (Making) Sichuan Province a Strong Industrial Province. During the conference that lasted from March 26 to March 31, 2006, many cadres attending the conference including the Sichuan provincial (communist) party secretary Zhang Xuezhong were shown and operated an actual system demonstrated at the conference. Type Hongguang-I Electro-optical radar is also designed to be compatible with H-6, JH-7, J-8, J-11 and other large aircraft. Based on the limited information released, Hongguang-I optronics has a maximum range up to 75 km, longer than the Izdeliye OLS-27 (36Sh) optronics with 50 km on Su-27, but shorter than the Izdeliye OLS-30 (52Sh) optronics on Su-30.
In comparison to Russian Izdeliye family of optronics such as OLS-27 (36Sh) on Su-27 and OLS-30 (52Sh) on Su-30 that weigh over 200 kg, the Chinese system is much more lighter and compact, but still not enough to be fitted into the nose of the aircraft when the current available radars are installed. As a result, only the podded version can be carried by earlier production models of JF-17. Many domestic Chinese sources have claimed that this is the reason why the radar selection of JF-17 has not yet been finalized, due to the need for a more compact and lighter one while maintaining the same capability at the same time in order to install the domestic optronics system internally like similar systems on F-14, MiG-29 and Su-27.
Helmet Mounted Sight (HMS)
Though the exact type of helmet mounted sights for the JF-17 has yet to be determined, it is known that the HMS will be standard. The JF-17 is compatible with a wide range of HMSes, and its HMS will be at least equal or better than the HMS offered for the Chengdu J-7E/F-7PG (J-7), which first appeared in 2002 at air shows and various defense / electronics exhibitions, such as CIDEX held in China. According to staffmembers from the developing firms and their advertisements at these exhibitions, the HMS offered for the J-7 is already better than the latest Russian HMS available on the export market, in that the Chinese HMS is specifically designed to improve the performance of the Russian system, and it outperforms its Russian counterparts including the ASP-AVD-21, Shchel series and Sura series in various fields:Fact|date=April 2008
*In comparison to the original standard Russian ASP-PVD-21 HMS on board the MiG-29 Fulcrum and the Flanker family, the field of view of the Chinese HMS for the J-7 is +/-90°, which is far greater than the mere +/-8° of the Russian ASP-PVD-21 HMS.
*In comparison to the latest Russian HMS available with +/-60° of field of view, the Chinese HMS for the J-7 still enjoys much greater field of view at +/-90°.
*The elevation of the latest Russian HMS designed to replace the original ASP-PVD-21 HMS on board the MiG-29 and the Flanker family is only +/-40°, while in contrast, the Chinese HMS for the J-7 is already +/-45°.
*The Chinese HMS for the J-7 already had a higher reliability than the Russian HMS.
*The Chinese HMS for the J-7 is easier and much cheaper to manufacture than its Russian counterparts.
Although the Chinese HMS for the J-7 has already enjoyed numerous advantages over the latest Russian HMS developed later, it still might not be the final type of HMS selected for the JF-17, because even as the Chinese HMS for the J-7 was first revealed in 2002, the Chinese manufacturers such as the 613th Institute had already started the development of newer HMS designed to replace the HMS for the J-7. Three major Chinese manufacturers, XBOE, the 613th Institute, and Luoyang Optoelectro Technology Development Center have already developed a variety of HMS systems with improvements including the adaptation of common attachments and power sources so that all night vision goggles and HMS are interchangeable, without the need to replace the entire system. The weight would be further reduced from the 200-gram weight of the Chinese HMS for the J-7, while the performance is further increased (mainly in the increase of elevation angles). While claims by various sources that the more advanced Chinese HMS on board the Chengdu J-10 developed from the HMS on board the J-7 would be selected for the JF-17 cannot be confirmed, the aircraft is certainly compatible with the more advanced Chinese HMS on board the J-10.Fact|date=April 2008
Electronic warfare
It has all the standard electronic warfare systems, such as radar warning receiver, missile approach warning system, etc.
*The computer can store more than 500 existing radar signals for identification, which is around 5 times of that F-7MP/P, and actually already stores more than 250 known radar signal patterns.
*360-degree field of view for the missile approach warning system with both infrared & ultraviolet spectrum detection.
**Very sensitive to the "afterburn" of missiles.
**The detection range is 60+ km.
**One detection sensor is in the tail and two at the front.
**Moreover, it can provide a certain capacity of tracking and positioning of approaching missiles.
*BM/KG300G Self protection jamming pod.
*KZ900 Electronic reconnaissance pod.
*Blue Sky navigation pod: Low altitude navigational and attack pod
*FILAT Forward-looking Infrared Laser Attack Targeting pod
*Other targeting pods
The MAWS(Missile Approach Warning System) scans in the IR, UV and visual spectrum, being able to detect incoming missiles from 20 km away.
1、UHF/VHF Communication antenna
2、Shortwave antenna
3、The omnidirectional synthesis radar warning locates /Self-defense electronic countermeasure
1-Digital electrostatic type atmosphere data pickoff
2-Incidence vane
3-AIFF Advanced friend-or-foe identification antenna
Communication
The JF-17 has two communication radios; one of them has the capacity for data link to exchange data from either a ground control center or an AWACS/AEW.
The modular design of solid state avionics has enabled the data link for the air-to-ground precision guided munitions to be carried internally, thus eliminating the need to carry external data link pods that are common for current Russian and Vietnam War era American systems, but this only applies to the radar or GPS guided air-to-surface missiles, because for television, infrared, or laser guided munitions, the aircraft lacks built-in electro-optics targeting and weapon control systems, so an external electro-optic targeting pod must be carried such as the Chinese built Blue Sky.
Engine
The current engine in the JF-17, the Russian RD-93, is now completely smoke-free. Truly impressive is that considering all its misgivings, the acceleration and quick response it can achieve is well within expectations. According to most test pilots, the engine's response is virtually instantaneous. Here is a comparison between the RD-93 and the Chinese WS-13:
:"Source: [
Grande Strategy RD-93 / WS-13] "
http://dc318.*******.com/img/mi3wj5Kk/rd93.JPG
Engine maintenance
Instead of being required to be sent back to the main overhaul factories in the rear for engine replacements, the aircraft engine can be readily replaced at the forward airbases in field conditions within two hours (one hour forty-five minutes has been achieved), providing the necessary maintenance equipment is all in place.
The Russian RD-93, despite "engineered" controversy by the Indian media, is slated to power at least the initial batches of the JF-17. The RD-93 is to be equiped with advanced crystal blade technology and a Digital Electronic Engine Control (DEEC). Other than improving the engine performance, the DEEC results in carefree handling under a wide range of conditions and at virtually all relevant altitudes.
The JF-17 has been designed from day one for ease of operations and maintainability. One such feature is that of a single point pressure refueling system. This significantly reduces the
turn around time, meaning more sorties can be generated, while maintenance intensive Indian aircraft remain grounded. This is furthered by the modular maintenance design of the aircraft. The level of the serviceability and ease of general maintenance is further illustrated by how panels and components are installed at man's height and a full computer-controlled fault diagnosis and analysis system can be relied upon.
Fuel system
*Total internal fuel: 5,130 lb [
http://www.pac.org.pk/amfsite-final/jf17specifications.html JF-17 Specifications] ]
*Single point pressure refueling system
*External Fuel:
**One (1) centerline droptank, 800 liters
**Two (2) under wing droptanks, 800/1,100 liters
Ground maintenance equipment
In comparison to Russian ground maintenance equipment for the Flanker family such as the Sukhoi Su-30, the Chinese claim that its indigenously-developed ground maintenance equipment for the JF-17 offers significant advantages to the current Russian one on the market, and the PLAAF has already begun to replace Russian ground maintenance equipment for the Flanker family for the following reasons:
*Like its Western counterparts, the Chinese ground maintenance equipment is not limited to serve a single type of aircraft; instead, it is designed to service a wide range of aircraft, including both civilian and military. In comparison, most Russian ground maintenance equipment for the Flanker family are purposely built and can only serve the aircraft in that family.
*The Chinese ground maintenance equipment utilizes solid state electronics, and has better reliability.
*Chinese equipment is based on the commercial off-the-shelf products that greatly reduce the logistic problems due to its commonality with similar commercial equipment available, while meeting the military standards in same time.
*Due to the adaptation of the commercial off-the-shelf products, Chinese equipment is cheaper to purchase, and, more importantly, cheaper to operate than the specially designed Russian ones, which have unit prices from at least $0.5 million to more than $1.0 million United States dollars.
*Chinese equipment adopts the multi-tasks workstation principle of similar American systems, and thus much fewer equipment is needed like the American ones. In comparison, most Russian ground maintenance equipment offered for export for the Flanker family is single-tasked, thus forcing the buyers to spend more money on purchasing every type in order to meet the complete maintenance requirements.
*Due to its similar design that follows Western systems, Chinese equipment is compact and can be deployed by air, like its Western counterparts. In contrast, Russian equipment for Flanker family is bulky and can only be transported on land, since it cannot fit inside cargo airplanes.
*Chinese equipment is versatile like similar Western systems, in that it can either be truck-mounted to increase mobility, or trailer-mounted to reduce cost. In contrast, the current Russian ground maintenance equipment on the market for the Flanker family only comes in truck-mounted form (as of 2006).
*Instead of being built by a single production complex associated with the aircraft manufacturer like the ground maintenance equipment of the [Flanker family, the complete set of the Chinese ground maintenance equipment is developed by different manufacturers of similar equipment used for commercial airplanes, so that buyers would have wider choice of suppliers, and would not have to pay higher prices, because they would not to be locked into the deal forced upon them by the aircraft manufacturer. The purchasers of Chinese equipment therefore are open to purchase Western components should they choose to, when there are better deals to be found.
*More importantly, since most of the Chinese equipment is for civilian use, there is far less likelihood of being embargoed like the Russian equipment for the Flanker family, which is purely for military use.
*The civilian usage of the multi-tasked Chinese equipment also means that the equipment can be better utilized for civilian aircraft, and thus reducing the cost of operation like similar Western systems. In contrast, not only is the Russian counterpart limited to military aircraft, it is also only limited to a single family of military aircraft, because many of the single-tasked Russian ground maintenance equipment purposely built for Flanker family can only be used for Flankers.
*Like similar Western systems of modular design, the Chinese ground maintenance equipment also has the option of modular design, so that when newer subsystems become available, they can be readily incorporated into the system by replacing the older ones on the racks.
Weaponry
The aircraft is fitted with modern Stores Management System incorporating accurate weapon delivery modes and solutions involving minimum pilot workload. The aircraft is capable of carrying some of the most modern as well as conventional weapons, including:
All weapon systems are designed to be compatible with both Western systems (ie. supporting MIL-STD-1760 data bus), Chinese systems and Pakistani systems as well. A total of 3,629 kg (8,000 lb) of ordnance can be loaded on the JF-17 Thunder. [Pakistan Aeronautical Complex.... Pakistan Aeronautical Complex ] ]
Cannon
One internal GSh-23-2 twin-barrel 23-mm [ [MILAVIA Aircraft - Chengdu FC-1/JF-17 Thunder Specifications MILAVIA Aircraft - Chengdu FC-1/JF-17 Thunder Specifications ] ] cannon has been installed on JF-17, which can be replaced with a 30-mm single-barrel cannon.
Air-to-air weaponry
The JF-17 is primarily an export-oriented fighter, thus it can be built according a customer's specifications and use a variety of Chinese and Western weapon systems.
These include air-to-air Beyond Visual Range missiles (BVRs).
Non-Chinese weapons:
*R-Darter BVR-AAM (proposed at IDEAS 2006, Karachi, Pakistan)
*A-Darter WVR-AAM (also proposed at IDEAS 2006)
*T-Darter BVR-AAM (also proposed at IDEAS 2006)
*IRIS-T WVR-AAM (also proposed at IDEAS 2006)
*AIM-9L/P Sidewinder WVR-AAM
*AIM-7F Sparrow BVR-AAM
*AIM-120C-5 BVR-AAM
*Magic-II - R550 Magic [ [Matra Magic-II Matra Magic-II ] ]
*MBDA MICA
*Aspide
*BLU-107 Durandal
Chinese weapons:
*PL-5/PL-5C
*PL-9 Chinese copy of Python-3 for within visual range combat
*SD-10 BVRAAM, a Beyond Visual Range missile
Air-to-ground weaponry
In addition to unguided bombs and rockets, the aircraft is adopted to deploy a wide range of precision guided munitions, including:
Non-Chinese weapons:
*GBU-10 Paveway II
*GBU-12 Paveway II
*Mark 82 bomb
*Mark 84 bomb
*DPGM (Precision Guided Bomb) - Denel (South Africa)
*Raptor-I precision-guided long-range glide bomb (60 km) - Denel (South Africa)
*Raptor-II precision-guided long-range glide bomb (120 km) - Denel (South Africa)
*Rockeye - CBU-100 Cluster Bomb
*Anti-ship missile such as Exocet and Harpoon missile.
*Russian KAB series laser guided bombs; these Russian bombs cannot be directly mounted on weapon pylons like Western or Chinese munitions, instead, added special adapter rails are needed for JF-17s when using them
Indigenous Pakistani weapons:
*H-2 Air to Ground Munition(60 km)
*H-4 Air to Ground Munition(120 km)
*Ra'ad Stand-off cruise mssile (350 km)
*HAFR-2 Anti-Runway bomb
Chinese weapons:
*FT (Fei Teng) series of GPS guided bombs
*LT (Lei Ting) of laser guided bombs
*LS (Lei Shi) series of GPS glide bombs
*C-101 Supersonic Anti-ship missile
*FL-7 Supersonic Anti-ship missile
*C-701 Air-to-surface missile
*TL-10 Anti-ship missile for boats with displacement up to 500 tons
*TL-6 Anti-ship missile for boats/ships with displacement up to 1,000 tons
*C-704 Anti-ship missile for ships with displacement up to 3,000-4,000 tons
*C-801/802 Anti-ship missile for ships with displacement greater than 4,000 tons
All precision guided munitions listed above are either GPS or radar guided, and when the television or laser guided munitions are deployed, addition electro-optical targeting pods such as the Chinese-built Blue Sky pod must be carried externally in order to provide guidance and targeting information.
JF-17 Thunder
Pakistan Aeronautical Complex
Physical Parameters
Length 49 ft
Height 15.5 ft
Wingspan 31 ft
Empty Weight 14,520 lb
Performance Parameters
Maximum Take Off Weight
27,300 lb
Max Mach No
1.6
Maximum Speed
700 Knots IAS
Service Ceiling
55,500 ft
Thrust to Weight Ratio
0.95
Maximum Engine Thrust
19,000 lb
G Limit
+8,-3
Ferry Range
1,880 NM
Armament
No of Stations
07
Total Load Capacity C Capacity capability
8000 lb
https://defence.pk/pdf/threads/jf-17-thunder-information-pool.71435/
JF-17's designers say that the strength of the Thunder lies in its advanced aerodynamics and state-of-the-art avionics. It is one of the only two current modern time fight*ers incorporated the latest research on intake design. In order to improve the aircraft's performance, study on diverterless supersonic intake has been in progress since 1999. Bump intake design on JF- 17 took almost two years with a number of intake models subjected to high and low speed wind tunnel tests. Analysis show that at high speeds, the bump works with forward-swept inlet cowls to give high performance, high total pressure recovery, low integrated distortion, and, good engine/intake matching. It redirects unwanted boundary layer airflow away from the inlets, essentially doing the job of heavier, more com*plex, and more costly approaches being used for because intake is one of the three major forward scatters of an aircraft (30%-35% contribution to aircraft forward Radar Cross Section (RCS)). In order to fully exploit the potential of the aircraft fly-by-wire system and improve the aircraft per*formance, JF-17 design has a wing fore body strike which is about 9% of the Wing area. This has resulted in better matching of the aerodynamic focus with the Center of Gravity (CG) and better harmonization of the air-to-air and air-to-ground CG vari*ations by taking advantage of the pitch digital fly-by-wire Flight Control Systems (FCS). This has improved not only the controllability but has also enhanced the performance through reduction of the supersonic drag. The salient features of "Thunder or Xia Long" enable it to outfit many competitors in the world. As a light weight, all weather, multi-role aircraft with maximum speed of Mach 1.6 (700 knots), high thrust*-to-weight ratio and hybrid flight con*trols, JF-17 gains comparative agili*ty and maneuverability in all regimes vis-a-vis fighters of the same class. Moreover, a state-of-the-art avionics package comprising modern concept of Man Machine Interface (MMI) with full Hands On Throttle-And-Stick (HOTAS) and glass cockpit make it comparable with even fourth generation fighters. This specific feature enhances its ability in all operational scenarios.
This multi-role, third generation air*craft is designed to be highly maneuverable with fly-by wire flight controls in pitch axis and stability augmentation system in the "Role and Yaw" axis. It will have the capa*bility to perform air defence, inter*diction, airfield strike, precision strike, and escort missions. It will allow long Combat Air Patrol (CAP) time at low level, thus affording large radius of action and thereby exceeding the PAF Air Staff require*ments in surface attack mode.
The aircraft is powered by reliable RD-93 engine, which like any other modern aircraft engine, is equipped with a Digital Electronic Engine Control (DEEC). Besides enhancing the engine performance, this makes engine handling carefree under all conditions and at all altitudes. Low Specific Fuel Consumption (LSFC) turbofan engine and low drag aero*dynamic design ensure its longer endurance and range. Because of its single point pressure refueling sys*tem, the aircraft has overall reduced turn around time. Modular mainte*nance design of the aircraft makes accessibility of the components quick and easy. All maintenance panels and components are installed at man's height for ease of mainte*nance. Computer-controlled fault diagnosis and analysis system not only reduce maintenance cost but also introduces the concept of "maintenance on fault only".
Long range radar and Active aircraft Beyond Visual Range (Active BVR) missile through effective integration with on board avionics provide pilot with a first shot capability. An elec*tro-optical self-protection suite with Missile Approach Warning system (MAWS) enhances its survivability under combat situations. Tactical datalink, with Track-While-Scan (TWS) and Dual Target Track (DTT) modes of the radar provide the pilot, an excellent Situation Awareness (SA) in all conditions. An integrated IFF interrogator along with colored displays provides easy cues for criti*cal decision-making.
JF-17's air combat capability is aug*mented by helmet-mounted display and all-aspect missiles affording high off-boresight launches. With its embedded data link and secure radios, the aircraft is expected to remain viable in future hostile bat*tles, and would prove to be an effec*tive low-cost high performance air defence fighter. It provides an affordable and efficient air-to-air mission capability. On the other hand, due to its advanced aerody*namic design, weapons carriage capability and avionics suite, it can strike the enemy, where it hurts him most in an offensive counter-air campaign. JF-17 thus would not only be lethal but will also be highly survivable.
Long range radar with multi-track and multi-target capabilities make Thunder a good choice for strike escort role. It can target the CAP air*craft while pushing the enemy away from the strike package. Its fire and forget capability reduces time on tar*get and thus ensures better surviv*ability. With the integration of AEW&C, JF-17 will have excellent SA even in enemy area to make crit*ical engagement and exit decisions. Furthermore, under hostile conditions, automated self-protection sys*tem of the aircraft affords high sur*vivability rate.
Large Radius Of Action (ROA) of Thunder and its weapon system capability make it an excellent light surface attack aircraft. Ring Laser Gyro (RLG) based Inertial Navigation System (INS) with embedded Global Positioning System (GPS) provides the capability of precision navigation over the entire ROA. It can carry multitude of external stores including conven*tional general purpose bombs, clus*ter bomb units, anti-runway bombs, anti-ship missiles and precision guided weapons that exist today. JF-*17 provides employment flexibility to suit the tactical conditions. JF-17's payload options make it airfield, pre*cision or maritime strike capable. It can be employed even for interdic*tion, armed reconnaissance, battle*field interdiction and close support roles.
It is designed to ensure effective MMI in all types of missions. Its efficient HOTAS controls and col*ored Smart Multi-Function Displays (SMFDs) provide ease of comprehension and control. The aircraft has a wide 24 degree Field Of View (FOV), Smart Head-Up-Display (SHOD) and Helmet-Mounted Display (HMD) provide the requisite menu based controls and displays to the pilot. The symbologies are designed to ensure high SA of the pilot both in air-to-air and surface attack missions. Its Identification Friend or Foe (IFF) interrogator for both air-to-air and air-to-surface applications is available to avoid fratricide in hostile conditions. This advanced MMI concept affords com*puter-controlled capability diagnosis and failure monitoring system to reduce the pilot's work-load. Therefore, the performance index of JF-17 is much higher than that of a second or third generation aircraft, both in air-to-air and air-to-surface scenarios. It would therefore not only meet the objectives for which it is being developed but would also truly prove to be a "Giant Leap" for our progressing aviation industry, thus paving the way for future growth in related fields.
https://defence.pk/pdf/threads/jf-17-thunder-information-pool.71435/
And this was Blk1, Blk2 had many improvements and Blk3 will be the ultimate with n AESA radar among many other high-tech additions and improvements..
JF-17B And JF-17 Blk2
