Apart from Thermal imaging is Turkey working on the new White Phosphorus Image Intensifiers?
Turkey currently produces UV solar blind image intensifiers for missile warning applications. Turkish NV goggles and weapon sights are equipped with 'Harris Corporation' image intensifying tubes.
From Aselsan;
Image Intensifier Tubes
UV solar blind image intensifier tubes are a key component
of helicopter missile warning systems. Qualification of a
the production line has been completed in 2016 and mass
production started successfully. To extend product application
to further platforms, engineering activities for the development
of new generation high photocathode sensitive tubes are in
progress.
And other developments;
Uncooled Infrared Thermal Detectors (Microbolometer)
Success gained through product focused activities on
Microbolometer Type Uncooled Infrared Detectors has in 2016
lead to the decision to invest in a mass production line within
ASELSAN’s facilities. Following the preparation of a multi-phase
investment plan, hardware procurement has started.
The facility is planned to be operational in 2018. Manufactured
detectors will primarily be used in ASELSAN’s product lines of
Thermal Weapon Binoculars, Armored Vehicle Thermal Sight
Systems and Missile Seeker Systems.
Cooled Infrared Photon Detectors
ASELSAN continued to be actively involved in the mass production of
Quantum Well Infrared Photodetectors (QWIP) which has a 640 x 512
format and 20 μm pitch. The process of integrating and deploying
QWIPs in EYE-Q Thermal Imaging Cameras, designed, optimized and
manufactured entirely by ASELSANfor border security purposes, has
come to its final stages.
ASELSAN has conducted research activities in developing infrared
detectors with Mercury Cadmium Telluride (MCT) epilayers.
Company’s main focus in this area is integrating these 640 x 512
format 15 μm pitch MCT detectors in ASELSAN made thermal
imaging systems for reconnaissance and surveillance such as Eye,
Sharpeye, Falconeye and targeting systems such as ASELPOD and
CATS.
Mercury Cadmium Telluride layers are deposited on Cadmium Zinc
Telluride (CZT) wafers. CZT is a militarily critical technology subjected
to export controls. ASELSAN engineers acquired the manufacturing
know-how of this critical material through their research efforts
conducted under a project contract (EYMIR) funded by the
Undersecretariat for Defence Industries.
