What happened to Marage in Karachi???
I relay want to know the cause of accident.
I relay want to know the cause of accident.
Mirage, F-7PG and other combat aircrafts
- Thread starter mourning sage
- Start date
fatman17
PDF THINK TANK: CONSULTANT
- Joined
- Apr 24, 2007
- Messages
- 32,563
- Reaction score
- 98
- Country
- Location
wait for PAF report i guess.
Danish saleem
SENIOR MEMBER
- Joined
- Mar 27, 2014
- Messages
- 2,231
- Reaction score
- 1
- Country
- Location
I think this is first Pic of F7Pg carrying 4 Aim-7 Missiles.
fatman17
PDF THINK TANK: CONSULTANT
- Joined
- Apr 24, 2007
- Messages
- 32,563
- Reaction score
- 98
- Country
- Location
ex-RAAF Mirage in PAF
After their retirement from service in 1987/88 forty eight RAAF Mirages were flown to Woomera for storage. They were offered for sale for A$100 million. On 15th April 1990 a contract was signed with Pakistan for fifty aircraft including ground equipment, engines, drop tanks and spares. (Pakistan Air Force project Blue Flash-V) The figure reported here was A$36 million however a number of Pakistani sources state the figure was A$27 million with the payment spread over seven years at approx. A$3.5 million per year. The ground equipment and spares package has been described as "a virtual gift". It should be mentioned that India was not at all happy with this deal and protested accordingly.
During November 1990 the Mirages were transported by road from Woomera to Whyalla. Two complete aircraft stored at Point Cook (A3-13 and A3-84) were also transported as well as five incomplete examples from Darwin, Orchard Hills and Dubbo. They were shipped by sea from Whyalla to Karachi. From Karachi harbour they were transported on trailers to PAF Base Masroor. After some dismantling they were flown by C-130 Hercules to the Pakistan Aeronautical Complex at Kamra.
There at the Mirage Rebuild Factory it was discovered that these ex-RAAF Mirages were in far better condition than expected and some did not require a complete overhaul. A new 2P+ inspection was developed for the initial recovery of thirty three aircraft. Another twelve aircraft had the General Overhaul and were eventually bought into service, some fitted with zero timed wings sourced from South Africa.
Of the fifty ex-RAAF Mirages acquired forty five eventually entered PAF service (details below). The remaining five were used for spares.
Thirty two single seat aircraft were later upgraded to ROSE 1 (Retrofit of Strike Element) the last one completed in June 1998. This avionics upgrade included Sagem integrated navigation/attack system, multifunction display, HOTAS, HUD, and self protection systems (RWR, chaff and flares).
Further upgrades include Grifo-M radar and AIM-9L AAMs.
(Sources differ as to if 32 or 33 received the ROSE 1 upgrade. I believe that only 32 received the upgrade because one aircraft crashed before it could be upgraded).
The ROSE 1 Mirages (redesignated in PAF service as Mirage IIIEA) were allocated to No.7 Squadron (Bandits) at Masroor in 1996 and to the Combat Commanders School (CCS) at Mushaf in 2003
Seven dual seat aircraft (redesignated in PAF service as Mirage IIIDA) were allocated to No.22 Squadron OCU and No.5 Squadron (Falcons). In June 2010 No.5 Squadron re-equipped with F-16s, the same aircraft that New Zealand was to buy.
The PAF also acquired the RAAF Mirage Photo Reconnaissance equipment and four aircraft configured in this role served with No.5 Squadron (Falcons)
In 2004 and 2007 Pakistan acquired 50 Mirages and 150 sealed engines from Libya. These aircraft will be converted to components to extend the life of the PAF Mirage fleet including the ex-RAAF examples.
In 2009 the Mirage IIIEAs started to be equipped with an in-flight refuelling probe, 90-583 serving as the prototype. PAF acquired four Ilyushin Il-78P Midas tanker aircraft from Ukraine and plan to equip 30 Mirages for in-flight refuelling
There have been many losses of PAF Mirages. The list isn't all that specific about which model was involved. Only two are confirmed as ex-RAAF with only one identified. There are probably others lost.
With the Pakistan being the world's largest current user of Mirages (200+ aircraft purchased from France, Australia, Lebanon, Spain and Libya), holding an extensive spare parts inventory and operating a dedicated Mirage Rebuild Factory the ex RAAF Dassault and GAF built Mirages look like they will still be flying well past their 50th birthdays. They are expected to remain in PAF service until replaced by the JF-17 Thunder in 5 to 10 years time
SUMMARY
50 complete aircraft exported by sea from Whyalla, South Australia
42 single seat Mirage IIIO;
40 stored at Woomera A3-2, -5, -6, -9, -10, -11, -12, -15, -17, -19, -21, -22, -23, -24, -25, -27, -31, -33, -34, -35,
-38, -39, -49, -53, -54, -56, -60, -61, -65, -68, -71, -73, -81, -83, -86, -87, -88, -93, -96, -99
2 stored at Point Cook A3-13, -84
32 eventually upgraded to ROSE 1 standard, 1 crashed prior to ROSE 1 upgrade. 4 Photo Recon. conversions, 5 used for spares.
8 dualseat Mirage IIID;A3-101, -103, -104, -108, -110, -111, -112, -113.7 into service, 1 used for spares.
Also 5 incomplete aircraft/fuselages; A3-7 (Darwin), -48, -78 (Dubbo), -57, -91 (Orchard Hills)
Pakistan Air Force serials.
Single seat; 90-5xx, were xx is the last two digits of the RAAF serial.
(I have been informed some may have had 89-5xx but haven't seen that myself)
Dual seat; Initially 90-6xx were xx was the last two digits of the RAAF serial (although some references have IIIDA serials as 67-6xx)
However at some stage changed to 90-8xx with the last two digits not matching any RAAF serial ie 90-860, -861, -874, -875, -876
As can be appreciated PAF information is scarce and the following list is derived from publicly available information.
Any further information, corrections and comments are welcome.
