Rocketsan için çalışan Adam nasıl heyecanla anlatıyor öyle
Mızrak-U hem karada hemde denizde korkulu rüya olacak
ROKETSAN tarafından geliştirilen Uzun Menzilli Tanksavar Füzesi MIZRAK-U'da geliştirme ve üretim süreci tamamlandı. Sıra teslimatlarda...
Mızrak-U hem karada hemde denizde korkulu rüya olacak
For non Turkish speakers.
The MRTP-34 (Kaan) attack boats will be armed with Mizrak-U Missiles. (Long range anti tank missiles)
Info about MIZRAK-U
MIZRAK-U, developed by ROKETSAN primarily for use from assault helicopters is an anti – tank missile system. It is, with the advanced technology it has, highly effective against all armored threats in the field
Click to see MIZRAK-U
brochure
Click to see L-MIZRAK-U
brochure
Properties of the Product
- MIZRAK-U, with its Imaging Infrared Seeker and Laser Seeker options, is an antitank missile, having a range of 8 km and lock on before / after launch and “fire and forget / fire and update” properties, used against armored targets, from Air to Ground as well as Ground to Ground.
Basic Properties
- Insensitive munitions (Level V)
- Tandem warhead effective against reactive armors
- Integration to various platforms (helicopter, UAV, land vehicle, stationary platform, light attack aircraft, naval platform)
- IIR or Laser Seeker options
- Lock on before / after – launch
- Fire and forget / Fire and update properties
- RF data link
- Smokeless composite solid propellant
Product Description
MIZRAK-U, which was developed by ROKETSAN primary for use from attack helicopters, is an antitank missile system. With its advanced technology it is highly effective against all armored threats in the field. .
MIZRAK-U, with its maximum range of 8 km and minimum range of 500 m is capable of operating all weather conditions and day/night.
MIZRAK-U, which can be used in Fire and Forget and Fire and Update modes, with the flexibility provided by its target update capability, offers to fire behind the mask position, fire against targets hiding behind mask and adjust hit point and damage assesment capability. MIZRAK-U, defined as the official antitank system of the National Attack Helicopter (T – 129) under development, can be integrated to various platforms (Helicopter, UAV, land Vehicle, Stationary Platform, Light Assault Aircraft, Naval Platform)
Technical Specifications
Diameter160 mm
Max. rangel8 km
Min. range0,5 km
Weight37,5 kg
Propellant typeHTPB-based reduced smoke composite propellant
Warhead typeInsensitive tandem warhead effective against armor with reactive protection
GuidanceImager Infrared (IIR) or Laser
Target TypesHeavy Armored / Armored Vehicles
PlatformsHelicopters (AH – 1 W, T – 129 ATAK etc.), UAV’s, Land Vehicles, Light Attack Aircraft, Naval Platforms and Stationary Platforms
"
MIZRAK-U | Long Range Anti Tank Missile « Roketsan
