JF-17 Block-3 -- Updates, News & Discussion

.


Attachments

  • IMG_4216.JPG
    279.9 KB · Views: 148
. . .
.
Lower your expectations guys it won't be drastically change but if hard points are 9 I am ready to give a party

.
Dont give us hope..........

s

o you have seen it???

Lower your expectations guys it won't be drastically change but if hard points are 9 I am ready to give a party
So 9 hp is not a change ? Man that would give it a whole badass look when fully loaded up


Attachments

  • upload_2019-12-7_9-44-54.jpeg
    25.2 KB · Views: 117
.
So, how many of members think, it would be 'stealthy'! how many of you think inlet, LERX, slats will have noticable changes! @All who wants to take a shot.
Flight Global said that the inlets will be widened a bit, but otherwise, you were quite clear that 'stealthiness' or 'low observable' (LO) airframes weren't the end-all-be-all.

.
So, how many of members think, it would be 'stealthy'! how many of you think inlet, LERX, slats will have noticable changes! @All who wants to take a shot.

Inlets are widened but still DSI

Slats are the same as the ones in B version

Tale is from the A version

Horizontal stabilizers are different

LERX received some modification


screenshot_20191113-141135-png.589119

.
Flight Global said that the inlets will be widened a bit, but otherwise, you were quite clear that 'stealthiness' or 'low observable' (LO) airframes weren't the end-all-be-all.
Bro, what would widening the intake be helpful for?

Inlets are widened but still DSI

Slats are the same as the ones in B version

Tale is from the A version

Horizontal stabilizers are different

LERX received some modification


screenshot_20191113-141135-png.589119
The new LERX gives a 5th gen illusion. What a design !!!
Btw horizontal stabilizers look the same

.
Bro, what would widening the intake be helpful for?
As the name implies, taking in more air. Remember, the bulk of thrust in a turbofan engine comes the fan that is driven by compressors & turbines thru combustion. So wider intakes means more thrust for the same fuel consumption, thus giving the flexibility to achieve longer ranges and/or higher speeds. This is not taking after burning into account.

. . . . .
