LTS
Laser Threat Sensor
LTS786P is an early warning device which gives audio and visual alarms of threat by sensing a laser beam aimed at it from any direction. The exact location of the threat is indicated by nine LEDs and has the capability to differentiate between a Laser Range Finder, Laser Target Designator or a Laser Target Tracker Signals. It can be used on stationary or moving objects of any size or shape.
- Wave length response 0.8 ~1.06 microns
- Can be fitted on tanks, bridges and installations
LTS 1 can be coupled with acoustic alarms, smoke generators and other counter-measures
http://gids.com.pk/lts
RABTA
C4I & Air Defence Automation System
- Scout is a mini UAV System which is designed for portability
- It is modular, portable, light weight and easy to deploy
- It is electric powered, capable of completely autonomous flight and carries an electro-optical payload for day time surveillance / reconnaissance
- Inferring the presence of valid targets form a series of plots and tracks received from different radars
- Calculating true trajectories of the target in presense of uncertainties imposed by the sensor as well as aircraft dynamics
- Recognizing and rejecting false targets
- Successfully tracking and predicting the optimal estimates of the target in the presence of clutter and false alarms
- Displaying target tracking information
- Forming correct association between tracks and observation from radars in different environments
- Successfully tracking the target during extreme condition of fast maneuver, formations, miss detection, cross-overs etc.
http://gids.com.pk/rabta
RIBAT
ESM System
Electronic Support Measures (ESM) system is the most important aspect of Electronic Warfare (EW), required for a variety of ground, surface and airborne applications, especially in maritime scenario. It is imperative for every surface naval platform to be equipped with ESM system for early detection and parameters measurement of friendly & hostile emitters.
RIBAT has been developed for surface applications and successfully tested and verified in the field. RIBAT covers almost all the features available in ESM systems being used by modern navies worldwide.
Features
- 100 percent intercept probability
- Wide operating frequency range
- High sensitivity & dynamic range
- Instantaneous frequency measurement.
- High frequency accuracy & resolution
- 360 degree spatial coverage
- Fast reaction time
- Threat identification
- Mission library
- Scan & pulse measurement analysis
http://gids.com.pk/ribat
SLTA
Slim Line Towed Array Sonar for Naval Application
Detection of targets by the naval ships and submarines has always been very difficult and challenging due to the peculiar sea and associated environmental conditions. However the radiated noise from own platform makes it difficult or at times even impossible to detect weak signals from silent or remote targets. The successful design and development of the SLTA has significantly enhanced the underwater detection capability of the naval platforms.
Main features
- Equally adaptable for surface ships or submarines
- Enhanced detection and classification due to longer array having wide acoustic aperture, reduced flow noise and efficient processing
- Smaller diameter for easier handling onboard to facilitate its deployment and retrieval during all weather and covert operations
Future applications
- SLTA for Submarines & Ships in passive mode
- Coastal defense system
- SLTA for surface Ship Applications consist of
- Active Towed Array Sonar
- Stand Alone Passive Array
- Divers, detection/ Offshore Harbour Defence Systems
- Geophysical Exploration Applications
- Seismic surveys etc
http://gids.com.pk/slta
ACOUSTIC RANGING OF NAVAL VESSELS
In today's naval warfare, knowledge of one's own acoustic signatures is the difference between the prey and the predator. Signature management facility provides own noise level in full range of audible frequency spectrum, by utilizing static and dynamic measurements of naval vessels i.e. ships, Mine Counter Measure Vessels (MCMVs) and submarines.
Acoustic Signature Management is a very specialized field which not only requires operational skills but also has a very strong proficient development and analytical aptitude. We can provide the said service to friendly navies in the region. It consists of Static Ranging known as Near Field Holography (NAH) and dynamic ranging of moving vessels in open sea.
http://gids.com.pk/acoustic-ranging-naval-vessels
ACMI SYSTEM
Air Combat Maneuvering Instrumentation System
The ACMI system is designed to be range-less and can be operated without any restriction in any area. The system records the "Time Space Position Information" (TSPI) of all the aircrafts involved in the training exercises along with their essential parameters onto removable data storage.
- An effective training tool for combat pilots
- Capture of weapon deployment events
- Exchange of data between the participating aircraft using realtime data link
- Notification to pilots of weapon event results such as hit and miss for missiles for real time kill removal functionality
- Real time warning to the pilots such as collision kill/miss etc.
- Recording of time syncronized relevant information for post mission debriefing replay like Chaff/Flare Dispenser, RWR, EW etc.
- Post launch missile fly out and bombing accuracy calculations
- The system is installed on Mirage / F-7P / F-16 aircraft
http://gids.com.pk/acmi-system
AUTOMATIC FIRE CONTROL SYSTEM
Up-gradation of 37mm Anti Aircraft Gun
The original 37mm twin barrel AD gun has been upgraded in order to meet the present combat threats. The upgraded gun with its new firing system gives a unique combination of modern technology resulting in a very reliable weapon system. Capable to track high speed targets coupled with auto ranging. The gun can be operated in three modes, i.e. joystick, handheld fire control and laser aiming sight.
- Sunlight viewable alpha numeric displays
- Provision of interfacing with multiple guns (optional)
- Off Gun tracking of target for stability
- Computer aided leveling
- Smart electronics for gun control
- Power electronics for motors
- Limit switch for safety arc range
- Emergency stop
- Motors for azimuthal & elevation movements
- Horizontal and vertical shaft encoder
- Fire safety switch
http://gids.com.pk/automatic-fire-control-system
NOD
Night Observation Device
NOD is a portable, long range multi-sensor system for target acquisition, border patrol and perimeter security. The NOD system comprises of digital magnetic compass, GPS, pan and tilt unit.
- Area surveillance
- Target acquisition
- Search and rescue
- Forward observation
- Perimeter security
- Border patrol
http://gids.com.pk/nod
Related Projects under RIMMS (NUST)
1. Design and Development of S-Band TRR Module for Phased-Array Radars
2. Design and Development of a See-Through-Wall (STW) Radar System for Personnel Sensing and Localization from Standoff Distances
http://www.nust.edu.pk/INSTITUTIONS/Centers/RIMMS/Research/Pages/Projects.aspx
