T-90S Main Battle Tank, Russia
The T-90S is the latest development in the T-series of Russian tanks and represents an increase in firepower, mobility and protection. It is manufactured by Uralvagonzavod in Nizhnyi Tagil, Russia.
The T-90S entered service with the Russian Army in 1992. In February 2001, the Indian Army signed a contract for 310 T-90S tanks: 124 were completed in Russia and the rest are being delivered in "knocked down" form for final assembly in India.
T-90S armament
The T-90S armament includes one 125mm 2A46M smoothbore gun, stabilised in two axes and fitted with a thermal sleeve. The gun tube can be replaced without dismantling inside the turret. The gun can fire a variety of ammunition including APDS (Armour Piercing Discarding Sabot), HEAT (high-explosive anti-tank), HE-FRAG (high-explosive fragmentation) as well as shrapnel projectiles with time fuses.
The T-90S gun can also fire the 9M119 Refleks (NATO designation AT-11 Sniper) anti-tank guided missile system. The range of the missile is 100m to 4,000m and takes 11.7 sec to reach maximum range. The system is intended to engage tanks fitted with ERA (explosive reactive armour) as well as low-flying air targets such as helicopters, at a range of up to 5km. The missile system fires either the 9M119 or 9M119M missiles which have semi-automatic laser beamriding guidance and a hollow charge warhead. Missile weight is 23.4kg. The guns automatic loader will feed both ordnance and missiles.
Also fitted is a coaxial 7.62mm PKT machine gun and a 12.7mm air defence machine gun. A 5.45mm AKS-74 assault rifle is carried on a storage rack.
Self protection
The T-90 tank is protected by both conventional armour-plating and explosive reactive armour.
The T-90 is fitted with the Shtora-1 defensive aids suite which is produced by Electronintorg of Russia. This system includes infrared jammer, laser warning system with four laser warning receivers, grenade discharging system which produces an aerosol screen and a computerised control system.
It is also fitted with NBC (nuclear, biological and chemical) protection equipment.
Fire control and observation
"The T-90S has the 1A4GT integrated fire control system (IFCS) which is automatic but with manual override."
The T-90S has the 1A4GT integrated fire control system (IFCS) which is automatic but with manual override for the commander. The IFCS contains the gunner's 1A43 day fire control system, gunner's TO1-KO1 thermal imaging sight which has a target identification range of 1.2km to 1.5km and commander's PNK-S sight.
The gunner's 1A43 day FCS comprises: 1G46 day sight / rangefinder with missile guidance channel, 2E42-4 armament stabiliser, 1V528 ballistic computer and DVE-BS wind gauge.
The commander's PNK-4S sight includes a TKN-4S (Agat-S) day / night sight which has identification ranges of 800m (day) and 700m (night).
The driver is equipped with a TVN-5 infrared night viewer.
Propulsion
The T-90S has a liquid-cooled V-84MS 618kW (840hp) four-stroke V-12 piston engine. This engine can be fuelled by T-2 or TS-1 kerosene and A-72 benzine, in addition to diesel. The tank can carry up to 1,600 litres of fuel in the main fuel tanks and fuel drums. The fuel tanks are reinforced with armour plating.
The tank is provided with a snorkel for deep fording and can ford 5m of water with equipment which can be deployed in 20 minutes.
The mechanical transmission includes primary reduction gear, two planetary final gearboxes and two planetary final drives. The running gear features torsion bar suspension with hydraulic shock absorbers at one, two and six road wheel stations and tracks with rubber-metallic pin hinges.
T-90SK Tank
The T-90SK tank is designed to provide command and control over subordinate units, facilitate communications with superior commanders, and conduct operations as part of units and subunits.
This command tank is a derivative of the T-90S tank and is distinguished by an R-168-100KBE HF radio set, TNA-4-3 tank navigation equipment set and PAB-2M aiming circle.
Its basic specifications are on par with the baseline T-90S model. The command tank’s armament system, protection systems, power plant, transmission, running gear, vision devices, deep-water fording kit, self-entrenching equipment, and mine-clearing equipment mountings are similar to those of the T-90S MBT.
